Product Description

Wireless portable six-gas monitor with advanced VOC detection capability

The MultiRAE is the most advanced portable chemical detector on the market. The MultiRAE delivers the broadest PID sensor

range in its class and the versatility to support 25 intelligent interchangeable sensor options (such as PID, NDIR for combustibles

and CO2, ammonia, chlorine, formaldehyde,and phosphine) to fully meet the monitoring needs in a variety of applications,including

industrial hygiene, personal protection, leak detection, and HazMat response. The MultiRAE’s optional wireless capability improves

safety by providing commanders and safety of cers real-time access to instrument readings and alarm status from any location

for better situational awareness and faster incident response.

Applications

• Industrial hygiene, personal protection, and leak detection in industries such as:

- Aviation (wingtankentry)

- Chemical

- Environmental

- Oil and gas

- Pharmaceutical

- Shipping/marine

• HazMat response

• Clandestine drug labs

• Highly versatile and customizable

• Best PID in its class (0 to 5,000 ppm range,

0.1 ppm resolution)

• Man Down Alarm with real-time remote wireless

notifcation

• Compliant with MIL-SPEC-810G performance

standard

• Fully automatic bump testing and calibration

with AutoRAE 2

Specifications

SIZE	7.6”H x 3.8”W x 2.6”D (193.96 x 96.56 mm)
WEIGHT	31 oz (880 g)
SENSORS	2.5 intelligent interchangeable field - replaceable sensors including PID for VOCs, electrochemical sensors for toxic gases and oxygen, combustible LEL and NDIR sensors, and CO₂ NDIR sensor
BATTERY OPTIONS, RUNTIME² AND RECHARGE TIME	- Rechargeable Li - Ion (<1.2 - hr. runtime, <6 - hr. recharge time)- Extended duration Li - Ion (<1.8 - hr. runtime, <9 - hr. recharge time)- Alkaline adapter with 4 x AA batteries (<1.60 - hr runtime)
DISPLAY	Monochrom graphical LCD display (128 x 64) with backlighting, Automatic screen "flip" feature
DISPLAY READOUT	- Real - time visual gas concentrations; PID measurement gas and correction factor; Main Down Alarm on/off; reading of companion indicator; battery status; datalogging on/off; wireless on/off and receptor quality- STEL, TWA, peak, and minimum values
KEYPAD BUTTONS	3 operation and programming keys (Mode, Y/n, and N/u)
SAMPLING	Built - in pump: Average flow rate 250 cc/min. Auto - shutoff in low - flow conditions
CALIBRATION	Automatic with AutoRAE 2 Test System (Calibration System) or manual
ALARMS	Wireless remote alarm notification audible (95 dB @ 30 cm) or vibration, visible (flashing bright red LED), and on - screen indication of alarm conditions- Main Down Alarm with pre - alarm and real - time remote wireless notification³
DATALOGGING	- Man - configurable datalogging (6 months @ 1 - minute intervals 24/7)- User - configurable datalogging intervals from 5 sec to 3,600 seconds- Data, travel charger, and AutoRAE set - up and Updates on PC via desktop charging and PC comm.
COMMUNICATION AND DATA DOWNLOAD	Cradle download and instrument set - up Automatic Upgrade and Calibration System
WIRELESS NETWORK	Wireless datalog and alarm status transmission via built - in RF modem (optional)- ProRAE Guardian Real - Time Wireless System or EnviroNet Host - based Closed - Loop System
WIRELESS RANGE (TYPICAL)	MultiRAE to EchoView II Mesh modem – 330 feet (100 meters)MultiRAE to RaLink USB2.0 RAEmesh Reader or RAEpoint – 660 feet (200 meters)MultiRAE to Wi - Fi Access Point – 330 feet (100 meters)
OPERATING TEMPERATURE	- 4° to 122°F (- 20° to 50°C)
HUMIDITY	0% to 95% relative humidity (non - condensing)
DUST AND WATER RESISTANCE	IP6 - 6 ingress protection rating (dust - tight and waterproof against hosing jets coming from all directions)
SAFETY CERTIFICATIONS	CSA: Class1, Division 1, Groups A, B, Cand D, T4ATEX: Class II, Division 1; Groups E, F, G (85°C)0575111G Ex ia IIC T4 Ga2G Ex ia IIC T4 Ga with IR Sensor installed1M1 Ex ia I MaIECEx: Ex ia IIC T4 GaEx ia IIC T4 Ga with IR Sensor installed1M1 Ex ia I MaIECEx/ANZ/NZ Ex ib IIC T4 GaEx ia IIC T4 Ga with IR Sensor installedEx ia I Ma
EMC/RFI PERFORMANCE TESTS	EMC directive: 2014/30/ECMIL - STD - 810G and 461F - B108.8C compliant, IEC CSA22 No. 2, 152 - ISA - 12.13.01
LANGUAGES	Arabic, Chinese, Czech, Danish, Dutch, English, French, German, Indonesian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, and Turkish
WARRANTY	- Four years on CO and H₂S sensors- Three years on non - consumable components and catalytic LEL sensors- One year on all other sensors, pump, battery, and other consumable parts
WIRELESS FREQUENCY RADIO APPROVALS	ISM license free: IEEE 802.15.4 Sub 1GHz, Wi - Fi 802.11 b/gFCC Part15, CE, R&TTE, Others⁴Succursal RM900A
